Bocklet
Ando 669
| Chassis | Iveco Daily 4X4 |
| Wheelbase | 3780 |
| GVW | 7000 |
| L x W x H | 6690 x 2272 x 3600 |
The compact vehicle with all-wheel drive chassis combines the advantages of a classic alcove motorhome with the versatility of an off-roader in this multifunctional body. The available space is optimally utilised. The beds in the alcove and the bunk bed in the rear offer enough space for 4 people. A wardrobe and fridge are fitted under the overhanging alcove bed. The separate storage space in the rear, an optimally planned double floor in the living area and wall cupboards provide space for everything you need for a long journey. The high-quality interior fittings in the bathroom and kitchen meet even the highest demands of travellers.
Technical Data
Chassis
| Chassis | Iveco Daily 4X4 |
| Wheelbase | 3780 |
| GVW | 7000 |
| Engine | 4-cylinder Diesel |
| Capacity | 2998 |
| Engine power | 129 |
Body
| cold bridge-free GRP sandwich construction | |
| Wall thickness | 50 |
| Roof thickness | 50 |
| Bottom thickness | 60 |
Interior
| Length | 4173 |
| Width | 2150 |
| Height | 2475 |
| Seats with belt | 4 |
| Front bed | 2 |
| Rear bed | 2 |
Specifications
Chassis and body
Ausstattungsdetails
Basisfahrzeug und Aufbau
- All-wheel drive
- Reversing camera
- Air conditioning
- GRP sandwich body without cold bridges
- cold bridge-free bocklet doors and flaps with GRP step profile,
- KSD hollow rubber seal and multi-point locking system
- Cab front wall in 50 mm GRP sandwich construction with
- lockable access door
- Electric access step with automatic control
- Real glass hinged window
- Real glass roof hatch
- External storage compartments in the apron area
- Double floor storage compartment under living area
Interior and options
- Furniture construction in combination of white-coated CPL panels with teak real wood panelling.
- Fronts partly in teak real wood veneer
- Longitudinal bed alcove
- Dinette seating group with leather upholstery
- Floor covering Vinyl planks in teak look
- Double floor
- Gas-powered hot water heating with integrated boiler
- Diesel-powered hot air heating
- Underfloor air conditioning
- Battery capacity 480Ah, Lithium Ion
- Inverter 2000VA
- Charger 80A
- Charging booster
- Solar system 720 WP with MPPT control
- Central control panel
- LED lights
- Separate toilet with permanent ventilation
- Bathroom in GRP sandwich construction with separate shower
- Household taps with single lever mixer
- 3-burner cooker with gas oven
- Gas tank 110 litres
- Compressor fridge 140 litres
- Fresh water tank approx. 260 litres
- Waste water tank 200 litres
